2005 CAT 304C CR Excavator(sold)
Call Today: 916.933.6050
Short Description
2005 CAT 304C CR Excavator(sold)
Long Description
2005 CATERPILLAR 304CCR
2005 304CCR, 2000HRS, TRACKS HAVE SOME MINOR CUTS, EROPS W/HEAT/AC, HYDRAULIC THUMB, SERVICED REGULARLY BY CAT.
YEAR: 2005
MANUFACTURER: CATERPILLAR
MODEL: 304CCR
PRICE: $29000.00
LOCATION: PLACERVILLE, CA
SPECIFICATIONS CAT 304C CR MINI EXCAVATOR
A. Shipping Length of Unit
17 ft in
5170 mm
C. Shipping Height of Unit
8.3 ft in
2550 mm
I. Max Cutting Height
17.3 ft in
5280 mm
J. Max Loading Height
12.1 ft in
3690 mm
K. Max Reach Along Ground
17.9 ft in
5460 mm
L. Max Vertical Wall Digging Depth
8 ft in
2440 mm
M. Max Digging Depth
10.8 ft in
3300 mm
A. Shipping Length of Unit
17.3 ft in
5290 mm
C. Shipping Height of Unit
8.3 ft in
2550 mm
I. Max Cutting Height
18 ft in
5480 mm
J. Max Loading Height
12.8 ft in
3900 mm
K. Max Reach Along Ground
19.2 ft in
5830 mm
L. Max Vertical Wall Digging Depth
9.1 ft in
3690 mm
M. Max Digging Depth
12.1 ft in
3690 mm
Dimensions
B. Width to Outside of Tracks
6.5 ft in
1980 mm
D. Length of Track on Ground
8.5 ft in
2580 mm
E. Ground Clearance
1.1 ft in
340 mm
G. Height to Top of Cab
8.3 ft in
2550 mm
H. Tail Swing Radius
3.5 ft in
1070 mm
O. Counterweight Clearance
2 ft in
615 mm
Undercarriage
F. Track Gauge
5.2 ft in
1580 mm
N. Shoe Size
16 in
400 mm
Specification
Engine
Make
Mitsubishi
Model
S4Q2
Gross Power
43.8 hp
32.7 kw
Net Power
42.2 hp
31.5 kw
Power Measured @
2400 rpm
Displacement
153 cu in
2505 L
Number of Cylinders
4
Operational
Operating Weight
10844 lb
4920 kg
Fuel Capacity
19 gal
72 L
Cooling System Fluid Capacity
2.9 gal
11 L
Hydrauilc System Fluid Capacity
20.6 gal
78 L
Engine Oil Capacity
1.9 gal
7 L
Operating Voltage
12 V
Alternator Supplied Amperage
50 amps
Hydraulic System Relief Valve Pressure
3553 psi
24500 kPa
Hydraulic Pump Flow Capacity
31.4 gal/min
119 L/min
Swing Mechanism
Swing Speed
9 rpm
Undercarriage
Shoe Size
16 in
400 mm
Max Travel Speed
2.8 mph
4.6 km/h
Track Gauge
5.2 ft in
1580 mm
Boom/Stick Option (HEX) 1
Boom/Stick Option (HEX) 1
Standard Stick
Shipping Height of Unit
8.3 ft in
2550 mm
Shipping Length of Unit
17 ft in
5170 mm
Max Digging Depth
10.8 ft in
3300 mm
Max Reach Along Ground
17.9 ft in
5460 mm
Max Cutting Height
17.3 ft in
5280 mm
Max Loading Height
12.1 ft in
3690 mm
Max Vertical Wall Digging Depth
8 ft in
2440 mm
Boom/Stick Option (HEX) 2
Boom/Stick Option (HEX) 2
Long Stick
Shipping Height of Unit
8.3 ft in
2550 mm
Shipping Length of Unit
17.3 ft in
5290 mm
Max Digging Depth
12.1 ft in
3690 mm
Max Reach Along Ground
19.2 ft in
5830 mm
Max Cutting Height
18 ft in
5480 mm
Max Loading Height
12.8 ft in
3900 mm
Max Vertical Wall Digging Depth
9.1 ft in
3690 mm
Dimensions
Width to Outside of Tracks
6.5 ft in
1980 mm
Height to Top of Cab
8.3 ft in
2550 mm
Ground Clearance
1.1 ft in
340 mm
Counterweight Clearance
2 ft in
615 mm
Tail Swing Radius
3.5 ft in
1070 mm
Length of Track on Ground
8.5 ft in
2580 mm
