1995 CAT 527 Skidder Dozer(sold)

1995 CATERPILLAR 527, GRAPPLE SKIDDER/DOZER, 7100HRS, ESCO FIXED GRAPPLE & WINCH DRUM, 6 WY BLADE, OROPS WITH AIR, GOOD CONDITION, UNDERCARRIAGE AT 60%, TRACKS AT 40%, ALWAYS PROFESSIONALLY MAINTAINED, 1000 HOURS ON RECENT MOTOR BUILD.

Hours: 7100
Location: Graeagle, CA
Price: $125,000

Selected Dimensions

Dimensions

A. OVERALL LENGTH

19.9 ft in

6070 mm

B. OVERALL WIDTH

8.9 ft in

2720 mm

C. HEIGHT TO TOP OF CAB

10.8 ft in

3300 mm

E. GROUND CLEARANCE

1.7 ft in

531.8 mm

H. REACH OF GRAPPLE AT GROUND LEVEL

5 ft in

1515 mm

I. TONG OPENING AT TIPS

8.3 ft in

2540 mm

Undercarriage

D. LENGTH OF TRACK ON GROUND

9.4 ft in

2850 mm

Specification

Engine

MODEL

3304

GROSS POWER

150 hp

111.9 kw

DISPLACEMENT

427.2 cu in

7 L

Operational

OPERATING WEIGHT

47134.8 lb

21380 kg

FUEL CAPACITY

67.6 gal

256 L

Undercarriage

WIDTH OF SHOES

22 in

560 mm

NUMBER OF TRACK ROLLERS PER SIDE

7

LENGTH OF TRACK ON GROUND

9.4 ft in

2850 mm

GROUND CONTACT AREA

4944.5 in2

3.2 m2

Dimensions

OVERALL WIDTH

8.9 ft in

2720 mm

BLADE WIDTH

10.4 ft in

3170 mm

HEIGHT TO TOP OF CAB

10.8 ft in

3300 mm

GROUND CLEARANCE

1.7 ft in

531.8 mm

OVERALL LENGTH

19.9 ft in

6070 mm

REACH OF GRAPPLE AT GROUND LEVEL

5 ft in

1515 mm

TONG OPENING AT TIPS

8.3 ft in

2540 mm

GRAPPLE CAPACITY – TONGS TIP TO TIP

9 ft2

0.84 m2

DRUM DIAMETER

10 in

254 mm

MAX LINE PULL – BARE DRUM

29200 lb

129.9 kN
